| Manufacturer Part Number: | 10120052001 |
|---|---|
| Manufacturer: | Harting |
| Product Category: | Modular Connectors - Plugs |
| Available Quantity: | 9023 Pieces |
| Unit Price: | Quote by Email |
| Description: | Plug Modular Connector 8p4c, 4 Power Position Shielded Cat5 IDC |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 10120052001 Datasheet |
| Internal Part Number | 898-10120052001 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | 10120052001.stp 10120052001.igs 10120052001.wrl | |
| Online Catalog | Han® 3A Series | |
| Category | Connectors, Interconnects | |
| Family | Modular Connectors - Plugs | |
| Manufacturer | Harting | |
| Series | Han® | |
| Packaging | Bulk | |
| Part Status | Active | |
| Connector Type | Plug | |
| Cable Type | Round Cable, Solid or Stranded Wires | |
| Number of Positions/Contacts | 8p4c, 4 Power | |
| Features | Hybrid | |
| Shielding | Shielded | |
| Ratings | Cat5 | |
| Ingress Protection | IP65/67 - Dust Tight, Water Resistant, Waterproof | |
| Termination | IDC | |
| Length | 3.785" (96.15mm) | |
| Color | Gray | |
| Wire Gauge | 22-24 AWG | |
| Contact Finish | - | |
| Contact Finish Thickness | - | |
| Contact Material | - | |
| Current Rating | - | |
| Voltage Rating | - | |
| Housing Material | - | |
| Shield Material | - | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 10120052001 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
10120052001 is in stock for immediate shipping now. We are the distributor of Harting all series components. The condition of 10120052001 is new and unused, you can buy 10120052001 Harting with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 10120052001.
