| Manufacturer Part Number: | 1714001038 |
|---|---|
| Manufacturer: | Molex, LLC |
| Product Category: | Backplane Connectors - Hard Metric, Standard |
| Available Quantity: | 9039 Pieces |
| Unit Price: | Quote by Email |
| Description: | 6PX8C DC ASSY UNGUIDED |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 1714001038 Datasheet |
| Internal Part Number | 898-1714001038 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Impel™ Backplane Interconnect System | |
| PCN Design/Specification | Multiple Devices 13/Nov/2015 | |
| PCN Assembly/Origin | Multiple Devices 30/Oct/2015 | |
| Online Catalog | Impel™ Series | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - Hard Metric, Standard | |
| Manufacturer | Molex, LLC | |
| Series | Impel™ 171400 | |
| Packaging | Tray | |
| Part Status | Active | |
| Connector Type | Receptacle, Female Sockets and Blade Sockets | |
| Connector Style | Impel™ | |
| Number of Positions | - | |
| Number of Positions Loaded | All | |
| Pitch | 0.075" (1.91mm) | |
| Number of Rows | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Press-Fit | |
| Connector Usage | Daughtercard | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Current Rating | - | |
| Voltage Rating | 150V | |
| Operating Temperature | -55°C ~ 85°C | |
| Features | Shielded | |
| Standard Package | 64 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 1714001038 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
1714001038 is in stock for immediate shipping now. We are the distributor of Molex, LLC all series components. The condition of 1714001038 is new and unused, you can buy 1714001038 Molex, LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 1714001038.
