| Manufacturer Part Number: | 17660042201 |
|---|---|
| Manufacturer: | Harting |
| Product Category: | Backplane Connectors - Specialized |
| Available Quantity: | 9061 Pieces |
| Unit Price: | Quote by Email |
| Description: | HAR-BUS HM POWER FEMALE 4P PL2 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 17660042201 Datasheet |
| Internal Part Number | 898-17660042201 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | 17660042201.stp 17660042201.igs 17660042201.wrl | |
| Online Catalog | HM Series | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - Specialized | |
| Manufacturer | Harting | |
| Series | har-bus® HM | |
| Packaging | Tube | |
| Part Status | Active | |
| Connector Usage | Backplane-to-Daughtercard | |
| Connector Type | Receptacle, Female Blade Sockets | |
| Connector Style | Blade Power | |
| Number of Positions | 4 | |
| Number of Positions Loaded | All | |
| Pitch | 0.118" (3.00mm) | |
| Number of Rows | - | |
| Number of Columns | - | |
| Mounting Type | Through Hole | |
| Termination | Press-Fit | |
| Contact Layout, Typical | 4 Power | |
| Features | - | |
| Contact Finish | - | |
| Contact Finish Thickness | - | |
| Color | - | |
| Current Rating | 20A | |
| Material Flammability Rating | - | |
| Operating Temperature | - | |
| Voltage Rating | - | |
| Standard Package | 40 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 17660042201 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
17660042201 is in stock for immediate shipping now. We are the distributor of Harting all series components. The condition of 17660042201 is new and unused, you can buy 17660042201 Harting with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 17660042201.
