Manufacturer Part Number: | 39880-0105 |
---|---|
Manufacturer: | Molex, LLC |
Product Category: | Terminal Blocks - Wire to Board |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 5 Position Wire to Board Terminal Block Horizontal with Board 0.200" (5.08mm) Through Hole |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 39880-0105 Datasheet |
Internal Part Number | 898-39880-0105 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
3D Model | 39880-0105.stp | |
PCN Assembly/Origin | Terminal Block Products Production 17/Sep/2014 | |
Category | Connectors, Interconnects | |
Family | Terminal Blocks - Wire to Board | |
Manufacturer | Molex Connector Corporation | |
Series | Eurostyle™ 39880 | |
Packaging | Bulk | |
Part Status | Active | |
Number of Levels | 1 | |
Positions Per Level | 5 | |
Pitch | 0.200" (5.08mm) | |
Mating Orientation | Horizontal with Board | |
Current | 13.5A | |
Voltage | 300V | |
Wire Gauge | 16-30 AWG | |
Mounting Type | Through Hole | |
Wire Termination | Screw - Rising Cage Clamp | |
Features | - | |
Color | Black | |
Operating Temperature | -40°C ~ 105°C | |
Housing Material | Thermoplastic | |
Contact Material - Plating | Phosphor Bronze - Tin Plated | |
Clamp Material - Plating | Brass - Nickel Plated | |
Screw Material - Plating | Steel - Zinc Chromate | |
Torque - Screw | 0.68 Nm (6 Lb-In) | |
Screw Thread | M3 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 39880-0105 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
39880-0105 is in stock for immediate shipping now. We are the distributor of Molex, LLC all series components. The condition of 39880-0105 is new and unused, you can buy 39880-0105 Molex, LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 39880-0105.
