| Manufacturer Part Number: | 4P02-2D02-DA |
|---|---|
| Manufacturer: | 3M |
| Product Category: | Backplane Connectors - Specialized |
| Available Quantity: | 9994 Pieces |
| Unit Price: | Quote by Email |
| Description: | STACK-THRU 64PIN SOLDER MODULE |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 4P02-2D02-DA Datasheet |
| Internal Part Number | 898-4P02-2D02-DA | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | 4P02-2D02-xx.x_t 4P02-2D02-xx.igs 4P02-2D02-xx.stp | |
| Online Catalog | 4P01 and 4P02 Series | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - Specialized | |
| Manufacturer | 3M | |
| Series | 4P02 | |
| Packaging | Tube | |
| Part Status | Active | |
| Connector Usage | - | |
| Connector Type | Stackthrough, (PC/104) | |
| Connector Style | PC/104 | |
| Number of Positions | 64 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 2 | |
| Number of Columns | - | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Contact Layout, Typical | - | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 3µin (0.08µm) | |
| Color | - | |
| Current Rating | 3A | |
| Material Flammability Rating | UL94 V-0 | |
| Operating Temperature | -40°C ~ 105°C | |
| Voltage Rating | - | |
| Standard Package | 665 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 4P02-2D02-DA | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
4P02-2D02-DA is in stock for immediate shipping now. We are the distributor of 3M all series components. The condition of 4P02-2D02-DA is new and unused, you can buy 4P02-2D02-DA 3M with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 4P02-2D02-DA.
