| Manufacturer Part Number: | 71M6543F-DB-CT |
|---|---|
| Manufacturer: | Maxim Integrated |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9013 Pieces |
| Unit Price: | Quote by Email |
| Description: | 71M6543 Single Converter Technology® Series Power Management, Energy/Power Meter Evaluation Board |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 71M6543F-DB-CT Datasheet |
| Internal Part Number | 898-71M6543F-DB-CT | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Compiling Meter Code with New Computation Engine Resolving Magnetic Issues with Pulse Transformers | |
| Design Resources | Development Tool Selector | |
| PCN Part Status Change | Silergy Transfer 2/Mar/2016 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Maxim Integrated | |
| Series | Single Converter Technology® | |
| Part Status | Discontinued | |
| Main Purpose | Power Management, Energy/Power Meter | |
| Embedded | No | |
| Utilized IC / Part | 71M6543 | |
| Primary Attributes | - | |
| Secondary Attributes | - | |
| Supplied Contents | 2 Boards, Cable, Power Supply | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 71M6543F-DB-CT | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
71M6543F-DB-CT is in stock for immediate shipping now. We are the distributor of Maxim Integrated all series components. The condition of 71M6543F-DB-CT is new and unused, you can buy 71M6543F-DB-CT Maxim Integrated with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 71M6543F-DB-CT.
