Manufacturer Part Number: | A10194 |
---|---|
Manufacturer: | Antenova |
Product Category: | RF Antennas |
Available Quantity: | 11010 Pieces |
Unit Price: | Quote by Email |
Description: | 2.4GHz, 5GHz WLAN PCB Trace RF Antenna 2.4GHz ~ 2.5GHz, 4.9GHz ~ 5GHz 1.8dBi, 4.1dBi Solder Surface Mount |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | A10194 Datasheet |
Internal Part Number | 898-A10194 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | IoT Product Selector | |
Online Catalog | Antenova - Embedded | |
Category | RF/IF and RFID | |
Family | RF Antennas | |
Manufacturer | Antenova | |
Series | Mixtus | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Frequency Group | UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz) | |
Frequency (Center/Band) | 2.4GHz, 5GHz | |
Frequency Range | 2.4GHz ~ 2.5GHz, 4.9GHz ~ 5GHz | |
Antenna Type | PCB Trace | |
Number of Bands | 2 | |
VSWR | 1.4, 1.8 | |
Return Loss | -11dB, -15dB | |
Gain | 1.8dBi, 4.1dBi | |
Power - Max | - | |
Features | - | |
Termination | Solder | |
Ingress Protection | - | |
Mounting Type | Surface Mount | |
Height (Max) | 0.035" (0.90mm) | |
Applications | WLAN | |
Standard Package | 2,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | A10194 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
A10194 is in stock for immediate shipping now. We are the distributor of Antenova all series components. The condition of A10194 is new and unused, you can buy A10194 Antenova with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for A10194.
