| Manufacturer Part Number: | A8520E24A91GR |
|---|---|
| Manufacturer: | Anaren |
| Product Category: | RF Transceiver Modules |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | RF TXRX MOD ISM>1GHZ TRACE ANT |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | A8520E24A91GR Datasheet |
| Internal Part Number | 898-A8520E24A91GR | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector IoT Product Selector | |
| PCN Design/Specification | RF Output Power Update Jan/2015 | |
| Category | RF/IF and RFID | |
| Family | RF Transceiver Modules | |
| Manufacturer | Anaren | |
| Series | PurePath™ | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| RF Family/Standard | General ISM > 1GHZ | |
| Protocol | - | |
| Modulation | - | |
| Frequency | 2.4GHz | |
| Data Rate | - | |
| Power - Output | 20dBm | |
| Sensitivity | -87dBm | |
| Serial Interfaces | I²C, I²S | |
| Antenna Type | Integrated, Trace | |
| Memory Size | - | |
| Voltage - Supply | 2.2 V ~ 3.6 V | |
| Current - Receiving | - | |
| Current - Transmitting | - | |
| Mounting Type | Surface Mount | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 34-SMD Module | |
| Standard Package | 500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | A8520E24A91GR | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
A8520E24A91GR is in stock for immediate shipping now. We are the distributor of Anaren all series components. The condition of A8520E24A91GR is new and unused, you can buy A8520E24A91GR Anaren with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for A8520E24A91GR.
