ADL5336-EVALZ

ADL5336-EVALZ
Manufacturer Part Number:ADL5336-EVALZ
Manufacturer:
Product Category:RF Evaluation and Development Kits, Boards
Available Quantity:9017 Pieces
Unit Price:Quote by Email
Description:EVAL BOARD FOR ADL5336
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: ADL5336-EVALZ Datasheet
ADL5336-EVALZ´s Parameters
Internal Part Number898-ADL5336-EVALZ
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Software DownloadADL5336 Eval Brd Software
Design ResourcesIoT Product Selector
Online Catalog ADL5336 Evaluation Board
CategoryRF/IF and RFID
FamilyRF Evaluation and Development Kits, Boards
ManufacturerAnalog Devices Inc.
Series-
Part StatusActive
TypeAmplifier
Frequency-
For Use With/Related ProductsADL5336
Supplied ContentsBoard
Standard Package 1
Weight0.001 KG
ApplicationEmail for details
Replacement PartADL5336-EVALZ
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

ADL5336-EVALZ is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of ADL5336-EVALZ is new and unused, you can buy ADL5336-EVALZ Analog Devices Inc. with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for ADL5336-EVALZ.
