| Manufacturer Part Number: | AS3694 DEMOBOARD |
|---|---|
| Manufacturer: | ams |
| Product Category: | Evaluation Boards - LED Drivers |
| Available Quantity: | 9012 Pieces |
| Unit Price: | Quote by Email |
| Description: | AS3694 12, Non-Isolated Output LED Driver Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | AS3694 DEMOBOARD Datasheet |
| Internal Part Number | 898-AS3694 DEMOBOARD | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector Lighting Product Selector | |
| Online Catalog | AS3694 Demo Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - LED Drivers | |
| Manufacturer | ams | |
| Series | - | |
| Part Status | Active | |
| Current - Output / Channel | 70mA | |
| Outputs and Type | 12, Non-Isolated | |
| Voltage - Output | 50V | |
| Features | Thermal Shutdown Protection | |
| Voltage - Input | 15 V ~ 50 V | |
| Supplied Contents | Board | |
| Utilized IC / Part | AS3694 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | AS3694 DEMOBOARD | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
AS3694 DEMOBOARD is in stock for immediate shipping now. We are the distributor of ams all series components. The condition of AS3694 DEMOBOARD is new and unused, you can buy AS3694 DEMOBOARD ams with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for AS3694 DEMOBOARD.
