| Manufacturer Part Number: | B5786-01 |
|---|---|
| Manufacturer: | Antenova |
| Product Category: | RF Antennas |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 2.4GHz, 5GHz Bluetooth, WLAN Molded RF Antenna 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.825GHz 4dBi, 3dBi Connector, SMA Male Snap-In |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | B5786-01 Datasheet |
| Internal Part Number | 898-B5786-01 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | IoT Product Selector | |
| Category | RF/IF and RFID | |
| Family | RF Antennas | |
| Manufacturer | Antenova | |
| Series | Flavus | |
| Packaging | Tray | |
| Part Status | Obsolete | |
| Frequency Group | UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz) | |
| Frequency (Center/Band) | 2.4GHz, 5GHz | |
| Frequency Range | 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.825GHz | |
| Antenna Type | Molded | |
| Number of Bands | 2 | |
| VSWR | 2 | |
| Return Loss | - | |
| Gain | 4dBi, 3dBi | |
| Power - Max | - | |
| Features | - | |
| Termination | Connector, SMA Male | |
| Ingress Protection | - | |
| Mounting Type | Snap-In | |
| Height (Max) | 0.152" (3.85mm) | |
| Applications | Bluetooth, WLAN | |
| Standard Package | 840 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | B5786-01 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
B5786-01 is in stock for immediate shipping now. We are the distributor of Antenova all series components. The condition of B5786-01 is new and unused, you can buy B5786-01 Antenova with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for B5786-01.
