| Manufacturer Part Number: | B78419A2289A003 |
|---|---|
| Manufacturer: | EPCOS (TDK) |
| Product Category: | Current Sense Transformers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | P100717 EP10 SMT CURRENT SENSE T |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | B78419A2289A003 Datasheet |
| Internal Part Number | 898-B78419A2289A003 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | SMT Current Transformer Series | |
| Featured Product | Current Sense Transformers | |
| Online Catalog | B78417 and B78419 Series | |
| Category | Transformers | |
| Family | Current Sense Transformers | |
| Manufacturer | EPCOS (TDK) | |
| Series | B78419 | |
| Part Status | Active | |
| Turns Ratio - Primary:Secondary | 1 : 70 | |
| Frequency | 50 ~ 250 kHz | |
| Inductance | 3mH | |
| Current Rating | 30A | |
| DC Resistance (DCR) | 0.5 mOhm Primary, 2.1 Ohm Secondary | |
| E.T. | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.535" L x 0.504" W (13.60mm x 12.80mm) | |
| Height - Seated (Max) | 0.567" (14.40mm) | |
| Termination Style | Gull Wing | |
| Standard Package | 200 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | B78419A2289A003 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
B78419A2289A003 is in stock for immediate shipping now. We are the distributor of EPCOS (TDK) all series components. The condition of B78419A2289A003 is new and unused, you can buy B78419A2289A003 EPCOS (TDK) with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for B78419A2289A003.
