| Manufacturer Part Number: | BLP8G10S-45PY |
|---|---|
| Manufacturer: | Ampleon USA Inc. |
| Product Category: | Transistors - FETs, MOSFETs - RF |
| Available Quantity: | 9147 Pieces |
| Unit Price: | Quote by Email |
| Description: | RF Mosfet LDMOS (Dual), Common Source 28V 224mA 952.5MHz ~ 957.5MHz 20.8dB 2.5W 4-HSOPF |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | BLP8G10S-45PY Datasheet |
| Internal Part Number | 898-BLP8G10S-45PY | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Soldering/Fatigue Alum Bond Wire | |
| Mfg Application Notes | AN10896 App Note | |
| Design Resources | RF Products Appl/Design Manual | |
| PCN Design/Specification | Metal Protrusions Position Chg 24/Nov/2015 | |
| Online Catalog | RF HEMT, HFET, LDMOS FETs | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - FETs, MOSFETs - RF | |
| Manufacturer | Ampleon USA Inc. | |
| Series | - | |
| Packaging | Digi-Reel® | |
| Part Status | Active | |
| Transistor Type | LDMOS (Dual), Common Source | |
| Frequency | 952.5MHz ~ 957.5MHz | |
| Gain | 20.8dB | |
| Voltage - Test | 28V | |
| Current Rating | - | |
| Noise Figure | - | |
| Current - Test | 224mA | |
| Power - Output | 2.5W | |
| Voltage - Rated | 65V | |
| Package / Case | SOT-1223-1 | |
| Supplier Device Package | 4-HSOPF | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | BLP8G10S-45PY | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
BLP8G10S-45PY is in stock for immediate shipping now. We are the distributor of Ampleon USA Inc. all series components. The condition of BLP8G10S-45PY is new and unused, you can buy BLP8G10S-45PY Ampleon USA Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for BLP8G10S-45PY.
