| Manufacturer Part Number: | CMD1522VRVGCTR8 |
|---|---|
| Manufacturer: | Visual Communications Company - VCC |
| Product Category: | LED Indication - Discrete |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Green, Red LED Indication - Discrete 2.1V Green, 2.8V Red 4-SMD, No Lead |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 2 (1 Year) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CMD1522VRVGCTR8 Datasheet |
| Internal Part Number | 898-CMD1522VRVGCTR8 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | CMD15-21 and CMD15-22 Series Rectangle with Flat Top 1206 Package LEDs | |
| Category | Optoelectronics | |
| Family | LED Indication - Discrete | |
| Manufacturer | Visual Communications Company - VCC | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Color | Green, Red | |
| Lens Color | Colorless | |
| Lens Transparency | Clear | |
| Millicandela Rating | 10mcd Green, 20mcd Red | |
| Lens Style/Size | Rectangle with Flat Top, 2.00mm x 1.50mm | |
| Voltage - Forward (Vf) (Typ) | 2.1V Green, 2.8V Red | |
| Current - Test | 20mA Green, 20mA Red | |
| Viewing Angle | - | |
| Mounting Type | Surface Mount | |
| Wavelength - Dominant | - | |
| Wavelength - Peak | 570nm Green, 640nm Red | |
| Features | - | |
| Package / Case | 4-SMD, No Lead | |
| Supplier Device Package | 1206 | |
| Size / Dimension | 3.20mm L x 2.70mm W | |
| Height (Max) | 1.10mm | |
| Standard Package | 2,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | CMD1522VRVGCTR8 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CMD1522VRVGCTR8 is in stock for immediate shipping now. We are the distributor of Visual Communications Company - VCC all series components. The condition of CMD1522VRVGCTR8 is new and unused, you can buy CMD1522VRVGCTR8 Visual Communications Company - VCC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CMD1522VRVGCTR8.
