Manufacturer Part Number: | CSD16408Q5C |
---|---|
Manufacturer: | Texas Instruments |
Product Category: | Transistors - FETs, MOSFETs - Single |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | MOSFET N-CH 25V 113A 8SON |
Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | CSD16408Q5C Datasheet |
Internal Part Number | 898-CSD16408Q5C | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | NexFET MOSFET Technology | |
Video File | NexFET Power Block PowerStack™ Packaging Technology Overview | |
Featured Product | DualCool NexFET CSD16 Q5C MOSFETs Create your power design now with TI’s WEBENCH® Designer | |
PCN Design/Specification | Qualification Revision A 01/Jul/2014 | |
Manufacturer Product Page | CSD16408Q5C Specifications | |
Online Catalog | N-Channel Standard FETs | |
Category | Discrete Semiconductor Products | |
Family | Transistors - FETs, MOSFETs - Single | |
Manufacturer | Texas Instruments | |
Series | NexFET™ | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
FET Type | MOSFET N-Channel, Metal Oxide | |
FET Feature | Standard | |
Drain to Source Voltage (Vdss) | 25V | |
Current - Continuous Drain (Id) @ 25°C | 22A (Ta), 113A (Tc) | |
Rds On (Max) @ Id, Vgs | 4.5 mOhm @ 25A, 10V | |
Vgs(th) (Max) @ Id | 2.1V @ 250µA | |
Gate Charge (Qg) @ Vgs | 8.9nC @ 4.5V | |
Input Capacitance (Ciss) @ Vds | 1300pF @ 12.5V | |
Power - Max | 3.1W | |
Operating Temperature | -55°C ~ 150°C (TJ) | |
Mounting Type | Surface Mount | |
Package / Case | 8-PowerTDFN | |
Supplier Device Package | 8-SON-EP (5x6) | |
Standard Package | 2,500 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | CSD16408Q5C | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
CSD16408Q5C is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of CSD16408Q5C is new and unused, you can buy CSD16408Q5C Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CSD16408Q5C.
