| Manufacturer Part Number: | CSD19534KCS |
|---|---|
| Manufacturer: | Texas Instruments |
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Available Quantity: | 9331 Pieces |
| Unit Price: | Quote by Email |
| Description: | MOSFET N-CH 100V 100A TO220 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | CSD19534KCS Datasheet |
| Internal Part Number | 898-CSD19534KCS | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Site Chg 04/Dec/2015 Site Chg 25/Jan/2016 | |
| Manufacturer Product Page | CSD19534KCS Specifications | |
| Online Catalog | N-Channel Standard FETs | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - FETs, MOSFETs - Single | |
| Manufacturer | Texas Instruments | |
| Series | NexFET™ | |
| Packaging | Tube | |
| Part Status | Active | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 100V | |
| Current - Continuous Drain (Id) @ 25°C | 100A (Ta) | |
| Rds On (Max) @ Id, Vgs | 16.5 mOhm @ 30A, 10V | |
| Vgs(th) (Max) @ Id | 3.4V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 22.2nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 1670pF @ 50V | |
| Power - Max | 118W | |
| Operating Temperature | -55°C ~ 175°C (TJ) | |
| Mounting Type | Through Hole | |
| Package / Case | TO-220-3 | |
| Supplier Device Package | TO-220-3 | |
| Standard Package | 50 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | CSD19534KCS | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
CSD19534KCS is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of CSD19534KCS is new and unused, you can buy CSD19534KCS Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for CSD19534KCS.
