| Manufacturer Part Number: | DC-VIDEO-TVP5146N |
|---|---|
| Manufacturer: | Altera |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Altera Dev Kits Stratix® III Series Video, Daughter Card Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DC-VIDEO-TVP5146N Datasheet |
| Internal Part Number | 898-DC-VIDEO-TVP5146N | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Altera | |
| Series | Stratix® III | |
| Part Status | Obsolete | |
| Main Purpose | Video, Daughter Card | |
| Embedded | No | |
| Utilized IC / Part | Altera Dev Kits | |
| Primary Attributes | Dual Composite Video Input - NTSC or PAL | |
| Secondary Attributes | 10-Bit BT.656 Output, Compatible with Expansion Connector, Standard on Most Altera Development Kits | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DC-VIDEO-TVP5146N | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DC-VIDEO-TVP5146N is in stock for immediate shipping now. We are the distributor of Altera all series components. The condition of DC-VIDEO-TVP5146N is new and unused, you can buy DC-VIDEO-TVP5146N Altera with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DC-VIDEO-TVP5146N.
