Manufacturer Part Number: | DC2249A |
---|---|
Manufacturer: | Linear Technology |
Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
Available Quantity: | 9017 Pieces |
Unit Price: | Quote by Email |
Description: | LTM4622 µModule® DC/DC, Step Down 2, Non-Isolated Outputs Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | DC2249A Datasheet |
Internal Part Number | 898-DC2249A | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | DC2249A Design Files DC2249A Schematic | |
Featured Product | LTM4622 Step-Down µModule Regulator | |
Online Catalog | LTM4622EV Demonstration Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
Manufacturer | Linear Technology | |
Series | µModule® | |
Part Status | Active | |
Main Purpose | DC/DC, Step Down | |
Outputs and Type | 2, Non-Isolated | |
Power - Output | - | |
Voltage - Output | 1.2V, 3.3V | |
Current - Output | 2.5A. 2.5A | |
Voltage - Input | 4 V ~ 20 V | |
Regulator Topology | Buck | |
Frequency - Switching | 1MHz | |
Board Type | Fully Populated | |
Supplied Contents | Board | |
Utilized IC / Part | LTM4622 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | DC2249A | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
DC2249A is in stock for immediate shipping now. We are the distributor of Linear Technology all series components. The condition of DC2249A is new and unused, you can buy DC2249A Linear Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DC2249A.
