| Manufacturer Part Number: | DS2155GNC2+ |
|---|---|
| Manufacturer: | Maxim Integrated |
| Product Category: | Interface - Telecom |
| Available Quantity: | 9490 Pieces |
| Unit Price: | Quote by Email |
| Description: | Telecom IC Single-Chip Transceiver 100-CSBGA (10x10) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DS2155GNC2+ Datasheet |
| Internal Part Number | 898-DS2155GNC2+ | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | DS21352/552, DS2151, DS2152, DS2141A, DS21Q42 Programming SLC-96 DS2151 Implementation of ANSI T1.231-1993 DS2151, DS2153 Device Identification DS2152, DS2154, DS2151, DS2153, DS21X5Y and DS2155 Three Channel Drop and Insert DS2152, DS2154, DS21x5Y, and DS2155 Interfacing to the MC68360 (QUICC32) T1/E1 Network Interface Design DS2151, DS2152, DS2153, DS2154 Dallas Single Chip Transceiver Crystal Selection Guide Transparent Operation on T1, E1 Framers and Transceivers DS2153 Programming, ETS 300-011 Remote Alarm Generation T1/E1 and T3/E3 Transformer Selection Guide Using RCLK in a BITS/SSU Application DS2155 vs. DS21x5y: Software and Hardware Considerations Interfacing the DS2155 to the MPC8260 J1 Japanese Standards T1/E1/J1 Dual Connector Interface Hitless Protection Switching with 1+1 Redundancy DS2155 Internal BERT Programming DS31256 and T1/E1 Interface NRZ Applications E1 Operation of Dallas Semiconductor Framers and SCTs HDLC Configuration of Framers and Transceivers Pulse Template Measurement DS2155 Monitor Mode Design Extended System Information Bus (ESIB) Control Application DS2155 and DS26401 Software Comparison Power-Fault Protection Layout Programming and Controlling the FDL on DS2141A, DS2151 Maxim Telecommunications Frequently Asked Questions Network Interface and Circuit Designs for Secondary Protection of the DS2155 Single-Chip Transceiver Switching Frame Mode In Live T1 Systems DS2155, DS21Q55, DS2156 Programming SLC-96 T1/E1/J1, N+1 Redundancy with Analog Switches Selecting a T1/E1/J1 Single-Chip Transceiver Elastic Store Operation T1/E1 Loopback Operation for Maxim T1/E1/J1 Transceivers DS2155 To DS21458 Migration DS2155 and DS26502 Software Comparison Measuring Return Loss on T3/E3/STS-1 LIUs JJ-20.11-Compatible Interface for the DS2155 and DS21455 SCTs DS21458 Quad and DS26528 Octal Transceiver Software Comparison DS2155 and DS26521 Software Comparison | |
| Product Training Modules | Lead (SnPb) Finish for COTS Long-Term Supply Program | |
| Online Catalog | Telecom Interface | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Telecom | |
| Manufacturer | Maxim Integrated | |
| Series | - | |
| Packaging | Tray | |
| Part Status | Active | |
| Function | Single-Chip Transceiver | |
| Interface | E1, HDLC, J1, T1 | |
| Number of Circuits | 1 | |
| Voltage - Supply | 3.14 V ~ 3.47 V | |
| Current - Supply | 75mA | |
| Power (Watts) | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 100-LFBGA, CSPBGA | |
| Supplier Device Package | 100-CSBGA (10x10) | |
| Includes | BERT Generator and Detector, CMI Coder and Decoder, HDLC Controller | |
| Standard Package | 240 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DS2155GNC2+ | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DS2155GNC2+ is in stock for immediate shipping now. We are the distributor of Maxim Integrated all series components. The condition of DS2155GNC2+ is new and unused, you can buy DS2155GNC2+ Maxim Integrated with us at a very low price and quick delivery.
