| Manufacturer Part Number: | DT080AF-6-3 |
|---|---|
| Manufacturer: | Curtis Industries |
| Product Category: | AC DC Desktop, Wall Adapters |
| Available Quantity: | 9103 Pieces |
| Unit Price: | Quote by Email |
| Description: | 24V 80W AC/DC External Desktop (Class I) Adapter Cord (Sold Separately) Input |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DT080AF-6-3 Datasheet |
| Internal Part Number | 898-DT080AF-6-3 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | DT080AF Series | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | AC DC Desktop, Wall Adapters | |
| Manufacturer | Curtis Industries | |
| Series | Tri-Mag, DT080AF | |
| Part Status | Active | |
| Region Utilized | International | |
| Form | Desktop (Class I) | |
| Input Type | Cord (Sold Separately) | |
| Voltage - Input | 90 ~ 264 VAC | |
| Voltage - Output | 24V | |
| Current - Output (Max) | 3.2A | |
| Power (Watts) | 80W | |
| No Load Power Consumption | 100mW (Max) | |
| Polarization | - | |
| Applications | ITE (Commercial), Medical | |
| Efficiency | Level VI | |
| Operating Temperature | -20°C ~ 60°C | |
| Output Connector | Power DIN, 4 Pin | |
| Size / Dimension | 5.71" L x 2.83" W x 1.65" H (145.0mm x 72.0mm x 42.0mm) | |
| Approvals | - | |
| Power (Watts) - Max | 77W | |
| Input Connector | IEC 320-C14 | |
| Cord Length | - | |
| Weight | 0.001 KG | |
| Standard Package | 20 | |
| Application | Email for details | |
| Replacement Part | DT080AF-6-3 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DT080AF-6-3 is in stock for immediate shipping now. We are the distributor of Curtis Industries all series components. The condition of DT080AF-6-3 is new and unused, you can buy DT080AF-6-3 Curtis Industries with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DT080AF-6-3.
