| Manufacturer Part Number: | DZ5S100D0R |
|---|---|
| Manufacturer: | Panasonic Electronic Components |
| Product Category: | Diodes - Zener - Arrays |
| Available Quantity: | 16857 Pieces |
| Unit Price: | Quote by Email |
| Description: | Zener Diode Array 2 Pair Common Anode 10V 150mW SSMini5-F4-B |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DZ5S100D0R Datasheet |
| Internal Part Number | 898-DZ5S100D0R | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Zener Diodes | |
| Featured Product | Wearables Technology Components | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | Silicon Epitaxial Planar Type Zener Diode Array | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Arrays | |
| Manufacturer | Panasonic Electronic Components | |
| Series | - | |
| Packaging | Digi-Reel® | |
| Part Status | Active | |
| Configuration | 2 Pair Common Anode | |
| Voltage - Zener (Nom) (Vz) | 10V | |
| Tolerance | - | |
| Power - Max | 150mW | |
| Impedance (Max) (Zzt) | 30 Ohm | |
| Current - Reverse Leakage @ Vr | 50nA @ 7V | |
| Voltage - Forward (Vf) (Max) @ If | 1V @ 10mA | |
| Operating Temperature | - | |
| Mounting Type | Surface Mount | |
| Package / Case | SOT-665 | |
| Supplier Device Package | SSMini5-F4-B | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DZ5S100D0R | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DZ5S100D0R is in stock for immediate shipping now. We are the distributor of Panasonic Electronic Components all series components. The condition of DZ5S100D0R is new and unused, you can buy DZ5S100D0R Panasonic Electronic Components with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DZ5S100D0R.
