Manufacturer Part Number: | GRS-2013A-3010 |
---|---|
Manufacturer: | CW Industries |
Product Category: | Rocker Switches |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Rocker Switch SPDT 16A (AC) 125V Panel Mount, Snap-In |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | GRS-2013A-3010 Datasheet |
Internal Part Number | 898-GRS-2013A-3010 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
3D Model | GRS-2013A.stp | |
Category | Switches | |
Family | Rocker Switches | |
Manufacturer | CW Industries | |
Series | 2000 | |
Packaging | Bulk | |
Part Status | Active | |
Circuit | SPDT | |
Switch Function | On-Off-On | |
Current Rating | 16A (AC) | |
Voltage Rating - AC | 125V | |
Voltage Rating - DC | - | |
Actuator Type | Concave (Curved) | |
Color - Actuator/Cap | Black | |
Actuator Marking | HI OFF LO | |
Illumination Type, Color | - | |
Illumination Voltage (Nominal) | - | |
Mounting Type | Panel Mount, Snap-In | |
Termination Style | Quick Connect - 0.187" (4.7mm) | |
Ingress Protection | - | |
Features | - | |
Panel Cutout Dimensions | Rectangular - 27.23mm x 12.19mm | |
Operating Temperature | -20°C ~ 105°C | |
Mechanical Life | 25,000 Cycles | |
Electrical Life | 25,000 Cycles | |
Standard Package | 500 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | GRS-2013A-3010 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
GRS-2013A-3010 is in stock for immediate shipping now. We are the distributor of CW Industries all series components. The condition of GRS-2013A-3010 is new and unused, you can buy GRS-2013A-3010 CW Industries with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for GRS-2013A-3010.
