Manufacturer Part Number: | HG-8002JA 40.0000M-PHCX |
---|---|
Manufacturer: | EPSON |
Product Category: | Oscillators |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 40MHz CMOS XO (Standard) Oscillator Surface Mount 5V 45mA Enable/Disable |
Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | HG-8002JA 40.0000M-PHCX Datasheet |
Internal Part Number | 898-HG-8002JA 40.0000M-PHCX | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Crystals and Oscillators | |
Family | Oscillators | |
Manufacturer | EPSON | |
Series | HG-8002JA | |
Packaging | Bulk | |
Part Status | Obsolete | |
Type | XO (Standard) | |
Frequency | 40MHz | |
Function | Enable/Disable | |
Output | CMOS | |
Voltage - Supply | 5V | |
Frequency Stability | ±30ppm | |
Operating Temperature | -40°C ~ 85°C | |
Current - Supply (Max) | 45mA | |
Ratings | - | |
Mounting Type | Surface Mount | |
Size / Dimension | 0.551" L x 0.386" W (14.00mm x 9.80mm) | |
Height | 0.185" (4.70mm) | |
Package / Case | 4-SMD, J-Lead | |
Current - Supply (Disable) (Max) | 30mA | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | HG-8002JA 40.0000M-PHCX | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
HG-8002JA 40.0000M-PHCX is in stock for immediate shipping now. We are the distributor of EPSON all series components. The condition of HG-8002JA 40.0000M-PHCX is new and unused, you can buy HG-8002JA 40.0000M-PHCX EPSON with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for HG-8002JA 40.0000M-PHCX.
