| Manufacturer Part Number: | IRAUDPS3 |
|---|---|
| Manufacturer: | Infineon Technologies |
| Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
| Available Quantity: | 9014 Pieces |
| Unit Price: | Quote by Email |
| Description: | IRS27952 - AC/DC, Primary Side 2, Non-Isolated Outputs Evaluation Board |
| Lead Free Status / RoHS Status: | Not applicable / Not applicable |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | IRAUDPS3 Datasheet |
| Internal Part Number | 898-IRAUDPS3 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Reference Design Library | IRAUDPS3: ±30V, 120W, 115V in | |
| PCN Assembly/Origin | Warehouse Transfer 29/Jul/2015 | |
| Online Catalog | IRS27952S Evaluation Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
| Manufacturer | Infineon Technologies | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | AC/DC, Primary Side | |
| Outputs and Type | 2, Non-Isolated | |
| Power - Output | - | |
| Voltage - Output | ±30V | |
| Current - Output | - | |
| Voltage - Input | 88 ~ 132 VAC, 176 ~ 264 VAC | |
| Regulator Topology | Resonant | |
| Frequency - Switching | - | |
| Board Type | Fully Populated | |
| Supplied Contents | Board | |
| Utilized IC / Part | IRS27952 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | IRAUDPS3 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
IRAUDPS3 is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of IRAUDPS3 is new and unused, you can buy IRAUDPS3 Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for IRAUDPS3.
