| Manufacturer Part Number: | IRMD22381Q |
|---|---|
| Manufacturer: | Infineon Technologies |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IR22381Q / IR22381Q - Power Management, Motor Control Evaluation Board |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | IRMD22381Q Datasheet |
| Internal Part Number | 898-IRMD22381Q | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Obsolescence/ EOL | Digital Control IC Design Kits 05/Nov/2013 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Infineon Technologies | |
| Series | - | |
| Part Status | Obsolete | |
| Main Purpose | Power Management, Motor Control | |
| Embedded | No | |
| Utilized IC / Part | IR22381Q / IR22381Q | |
| Primary Attributes | 3-Ph, ACIM / BLAC, 380V @ 25A, With Brake, 1200V DC Bus Capable | |
| Secondary Attributes | ECONO2-PIM IGBT Module Compatible | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | IRMD22381Q | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
IRMD22381Q is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of IRMD22381Q is new and unused, you can buy IRMD22381Q Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for IRMD22381Q.
