| Manufacturer Part Number: | ISL6609AIRZ-T |
|---|---|
| Manufacturer: | Intersil |
| Product Category: | PMIC - Gate Drivers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC MOSFET DRVR SYNC BUCK 8-QFN |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ISL6609AIRZ-T Datasheet |
| Internal Part Number | 898-ISL6609AIRZ-T | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Other | Bond Wire and Assembly Facilities 21/Nov/2013 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Manufacturer | Intersil | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Driven Configuration | Half-Bridge | |
| Channel Type | Synchronous | |
| Number of Drivers | 2 | |
| Gate Type | N-Channel MOSFET | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Logic Voltage - VIL, VIH | 1V, 2V | |
| Current - Peak Output (Source, Sink) | -, 4A | |
| Input Type | Non-Inverting | |
| High Side Voltage - Max (Bootstrap) | 36V | |
| Rise / Fall Time (Typ) | 8ns, 8ns | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-VQFN Exposed Pad | |
| Supplier Device Package | 8-QFN (3x3) | |
| Standard Package | 6,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ISL6609AIRZ-T | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ISL6609AIRZ-T is in stock for immediate shipping now. We are the distributor of Intersil all series components. The condition of ISL6609AIRZ-T is new and unused, you can buy ISL6609AIRZ-T Intersil with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ISL6609AIRZ-T.
