| Manufacturer Part Number: | ISL8130EVAL3Z |
|---|---|
| Manufacturer: | Intersil |
| Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
| Available Quantity: | 9015 Pieces |
| Unit Price: | Quote by Email |
| Description: | ISL8130 - DC/DC, Step Up or Down 1, Non-Isolated Outputs Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ISL8130EVAL3Z Datasheet |
| Internal Part Number | 898-ISL8130EVAL3Z | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Power Management: ISL8117 60 V Synchronous Buck Controller | |
| Design Resources | Development Tool Selector | |
| Online Catalog | ISL8130 Evaluation Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
| Manufacturer | Intersil | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | DC/DC, Step Up or Down | |
| Outputs and Type | 1, Non-Isolated | |
| Power - Output | - | |
| Voltage - Output | 10V | |
| Current - Output | 2A | |
| Voltage - Input | 5.6 V ~ 16 V | |
| Regulator Topology | Boost, Buck, Fly Back | |
| Frequency - Switching | - | |
| Board Type | Fully Populated | |
| Supplied Contents | Board | |
| Utilized IC / Part | ISL8130 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ISL8130EVAL3Z | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ISL8130EVAL3Z is in stock for immediate shipping now. We are the distributor of Intersil all series components. The condition of ISL8130EVAL3Z is new and unused, you can buy ISL8130EVAL3Z Intersil with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ISL8130EVAL3Z.
