Manufacturer Part Number: | ISL8203MIRZ |
---|---|
Manufacturer: | Intersil |
Product Category: | DC DC Converters |
Available Quantity: | 9669 Pieces |
Unit Price: | Quote by Email |
Description: | DC/DC CONVERTER DUAL 0.8-5V 30W |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ISL8203MIRZ Datasheet |
Internal Part Number | 898-ISL8203MIRZ | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | ISL8203M Analog Power Module FPGA Reference Design | |
Featured Product | ISL8203M Power Module | |
Category | Power Supplies - Board Mount | |
Family | DC DC Converters | |
Manufacturer | Intersil | |
Series | - | |
Packaging | Tube | |
Part Status | Active | |
Type | Non-Isolated PoL Module | |
Number of Outputs | 2 | |
Voltage - Input (Min) | 2.85V | |
Voltage - Input (Max) | 6V | |
Voltage - Output 1 | 0.8 ~ 5 V | |
Voltage - Output 2 | 0.8 ~ 5 V | |
Voltage - Output 3 | - | |
Current - Output (Max) | 3A, 3A | |
Power (Watts) - Manufacture Series | - | |
Voltage - Isolation | - | |
Applications | ITE (Commercial) | |
Features | OCP, OTP, UVLO | |
Mounting Type | Surface Mount | |
Package / Case | 23-QFN | |
Size / Dimension | 0.35" L x 0.26" W x 0.07" H (9.0mm x 6.5mm x 1.9mm) | |
Operating Temperature | -40°C ~ 85°C | |
Efficiency | 95% | |
Power (Watts) - Max | - | |
Standard Package | 338 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ISL8203MIRZ | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ISL8203MIRZ is in stock for immediate shipping now. We are the distributor of Intersil all series components. The condition of ISL8203MIRZ is new and unused, you can buy ISL8203MIRZ Intersil with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ISL8203MIRZ.
