LC2259OANP

LC2259OANP
Manufacturer Part Number:LC2259OANP
Manufacturer:
Product Category:Pushbutton Switches
Available Quantity:9711 Pieces
Unit Price:Quote by Email
Description:Pushbutton Switch DPDT Standard Through Hole, Right Angle
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: LC2259OANP Datasheet
LC2259OANP´s Parameters
Internal Part Number898-LC2259OANP
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
RoHS InformationLC Series RoHS Cert of Compliance
CategorySwitches
FamilyPushbutton Switches
ManufacturerE-Switch
SeriesLC
PackagingBulk
Part StatusActive
TypeStandard
CircuitDPDT
Switch FunctionOn-Mom
Current Rating300mA (DC)
Voltage Rating - AC-
Voltage Rating - DC30V
Actuator TypePlunger for Cap
Color - Actuator/Cap-
Illumination Type, Color-
Illumination Voltage (Nominal)-
Mounting TypeThrough Hole, Right Angle
Termination StylePC Pin
Ingress Protection-
Features-
Panel Cutout Dimensions-
Operating Temperature-20°C ~ 85°C
Mechanical Life-
Electrical Life10,000 Cycles
Standard Package 350
Weight0.001 KG
ApplicationEmail for details
Replacement PartLC2259OANP
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

LC2259OANP is in stock for immediate shipping now. We are the distributor of E-Switch all series components. The condition of LC2259OANP is new and unused, you can buy LC2259OANP E-Switch with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for LC2259OANP.
