| Manufacturer Part Number: | LMZ31530RLGT |
|---|---|
| Manufacturer: | Texas Instruments |
| Product Category: | DC DC Converters |
| Available Quantity: | 9510 Pieces |
| Unit Price: | Quote by Email |
| Description: | DC/DC CONVERTER 0.6-3.6V 108W |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | LMZ31530RLGT Datasheet |
| Internal Part Number | 898-LMZ31530RLGT | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Powering FPGAs with SIMPLE SWITCHER® LMZ3 Power Modules SIMPLE SWITCHER® DC-DC Regulator and Module Portfolio Overview Power SIMPLE SWITCHER Nano Modules Overview | |
| Video File | Wide VIN Power Design with LMZ3 SIMPLE SWITCHER Power Module SIMPLE SWITCHER® Power Modules with High Power Density SIMPLE SWITCHER Synchronous Regulator Family Overview The Most Interesting Engineer in the World Layout Tips for Radiated EMI Reduction in Your Designs Thermal Design Made Simple Loop Compensation Made SIMPLE WEBENCH PCB Export for Synchronous SIMPLE SWITCHER Devices | |
| Design Resources | LMZ31530 Design with WEBENCH® Power Designer | |
| Featured Product | LMZ31520/30 SIMPLE SWITCHER® Power Modules Analog Solutions for Xilinx FPGAs and CPLDs – Texas Instruments | DigiKey | |
| Reference Design Library | LMZ31530EVM-002: 0.6V ~ 3.6V @ 30A, 3 ~ 14.5V in | |
| PCN Assembly/Origin | Assembly/Test Site Addition 28/May/2015 | |
| Manufacturer Product Page | LMZ31530RLGT Specifications | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | SIMPLE SWITCHER® LMZ31530 Power Modules Series | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Manufacturer | Texas Instruments | |
| Series | SIMPLE SWITCHER® | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 3V | |
| Voltage - Input (Max) | 14.5V | |
| Voltage - Output 1 | 0.6 ~ 3.6 V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 30A | |
| Power (Watts) - Manufacture Series | - | |
| Voltage - Isolation | - | |
| Applications | ITE (Commercial) | |
| Features | Remote On/Off, OCP, OTP, UVLO | |
| Mounting Type | Surface Mount | |
| Package / Case | 72-BQFN | |
| Size / Dimension | 0.64" L x 0.60" W x 0.23" H (16.2mm x 15.2mm x 5.9mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 96% | |
| Power (Watts) - Max | - | |
| Standard Package | 250 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | LMZ31530RLGT | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
LMZ31530RLGT is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of LMZ31530RLGT is new and unused, you can buy LMZ31530RLGT Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LMZ31530RLGT.
