Manufacturer Part Number: | LPT22 |
---|---|
Manufacturer: | Artesyn Embedded Technologies |
Product Category: | AC DC Converters |
Available Quantity: | 9292 Pieces |
Unit Price: | Quote by Email |
Description: | AC/DC CONVERTER 5V +/-12V 25W |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | LPT22 Datasheet |
Internal Part Number | 898-LPT22 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
RoHS Information | RoHS Cert of Compliance | |
PCN Packaging | CSA Marking 20/Sep/2013 | |
Online Catalog | LPT25 Series | |
Category | Power Supplies - External/Internal (Off-Board) | |
Family | AC DC Converters | |
Manufacturer | Artesyn Embedded Technologies | |
Series | LPT25 | |
Part Status | Active | |
Type | Open Frame | |
Number of Outputs | 3 | |
Voltage - Input | 85 ~ 264 VAC | |
Voltage - Output 1 | 5V | |
Voltage - Output 2 | 12V | |
Voltage - Output 3 | -12V | |
Voltage - Output 4 | - | |
Current - Output (Max) | 3A, 1.5A, 500mA | |
Power (Watts) | 25W (40W Forced Air) | |
Applications | ITE (Commercial) | |
Voltage - Isolation | - | |
Efficiency | 70% | |
Operating Temperature | 0°C ~ 70°C (With Derating) | |
Features | Adjustable Output, DC Input Capable, Remote Sense, Universal Input | |
Mounting Type | Chassis Mount | |
Size / Dimension | 5.00" L x 3.00" W x 1.14" H (127.0mm x 76.2mm x 29.0mm) | |
Minimum Load Required | Yes | |
Approvals | CB, CE | |
Power (Watts) - Max | 25W (40W Forced Air) | |
Standard Package | 80 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | LPT22 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
LPT22 is in stock for immediate shipping now. We are the distributor of Artesyn Embedded Technologies all series components. The condition of LPT22 is new and unused, you can buy LPT22 Artesyn Embedded Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LPT22.
