Manufacturer Part Number: | MA3TNP1600-S3 |
---|---|
Manufacturer: | Amphenol Sine Systems Corp |
Product Category: | Circular Connectors - Housings |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 16 Position Circular Connector Receptacle for Male or Female Contacts Panel Mount, Bulkhead - Front Side Nut Shielded, Strain Relief |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MA3TNP1600-S3 Datasheet |
Internal Part Number | 898-MA3TNP1600-S3 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Connectors, Interconnects | |
Family | Circular Connectors - Housings | |
Manufacturer | Amphenol Sine Systems Corp | |
Series | MotionGrade™ M23 A | |
Packaging | Bulk | |
Part Status | Active | |
Connector Type | Receptacle for Male or Female Contacts | |
Number of Positions | 16 | |
Shell Size - Insert | M23-16 | |
Shell Size, MIL | - | |
Contact Type | Crimp | |
Contact Size | 1.0mm | |
Mounting Type | Panel Mount, Bulkhead - Front Side Nut | |
Fastening Type | Threaded | |
Orientation | P | |
Shell Material, Finish | Zinc Die Cast, Nickel Plated | |
Ingress Protection | IP67 - Dust Tight, Waterproof | |
Features | Shielded, Strain Relief | |
Note | Contacts Not Provided | |
Standard Package | 200 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MA3TNP1600-S3 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MA3TNP1600-S3 is in stock for immediate shipping now. We are the distributor of Amphenol Sine Systems Corp all series components. The condition of MA3TNP1600-S3 is new and unused, you can buy MA3TNP1600-S3 Amphenol Sine Systems Corp with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MA3TNP1600-S3.
