Manufacturer Part Number: | MAX9730EVKIT+ |
---|---|
Manufacturer: | Maxim Integrated |
Product Category: | Evaluation Boards - Audio Amplifiers |
Available Quantity: | 9012 Pieces |
Unit Price: | Quote by Email |
Description: | MAX9730 - 1-Channel (Mono) Output Class G Audio Amplifier Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MAX9730EVKIT+ Datasheet |
Internal Part Number | 898-MAX9730EVKIT+ | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Mfg Application Notes | Amplifier Considerations in Ceramic Speaker Applications Class G and Charge-Pump Technologies Maximize Efficiency in Boosted Amplifiers with Minimal Support Components | |
Product Training Modules | Lead (SnPb) Finish for COTS Long-Term Supply Program | |
Design Resources | Development Tool Selector | |
Online Catalog | MAX9730 Evaluation Kit | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - Audio Amplifiers | |
Manufacturer | Maxim Integrated | |
Series | - | |
Part Status | Active | |
Amplifier Type | Class G | |
Output Type | 1-Channel (Mono) | |
Max Output Power x Channels @ Load | 2.4W x 1 @ 8 Ohm | |
Voltage - Supply | 2.7 V ~ 5.5 V | |
Board Type | Fully Populated | |
Utilized IC / Part | MAX9730 | |
Supplied Contents | Board | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MAX9730EVKIT+ | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MAX9730EVKIT+ is in stock for immediate shipping now. We are the distributor of Maxim Integrated all series components. The condition of MAX9730EVKIT+ is new and unused, you can buy MAX9730EVKIT+ Maxim Integrated with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MAX9730EVKIT+.
