| Manufacturer Part Number: | MC9RS08KA1CDBR |
|---|---|
| Manufacturer: | NXP Semiconductors |
| Product Category: | Embedded - Microcontrollers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | RS08 RS08 Microcontroller IC 8-Bit 10MHz 1KB (1K x 8) FLASH 6-QFN-EP (3x3) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | MC9RS08KA1CDBR Datasheet |
| Internal Part Number | 898-MC9RS08KA1CDBR | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | USBSpyder08 Discovery Kit MC9RS08KA8 Microcontroller | |
| Design Resources | Development Tool Selector | |
| PCN Obsolescence/ EOL | Multiple Devices 03/Oct/2012 | |
| PCN Design/Specification | Copper Wire Conversion 20/May/2014 Copper Wire Conversion 09/Jul/2014 Design Change Retraction 16/Sep/2014 QFN 3X3.4X4,5X5 Assembly Site 12/Nov/2015 | |
| PCN Assembly/Origin | Multiple Devices Test 14/Aug/2013 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Manufacturer | Freescale Semiconductor - NXP | |
| Series | RS08 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Core Processor | RS08 | |
| Core Size | 8-Bit | |
| Speed | 10MHz | |
| Connectivity | - | |
| Peripherals | LVD, POR, WDT | |
| Number of I/O | 2 | |
| Program Memory Size | 1KB (1K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 63 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 5.5 V | |
| Data Converters | - | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Package / Case | 6-VDFN Exposed Pad | |
| Supplier Device Package | 6-QFN-EP (3x3) | |
| Standard Package | 2,500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | MC9RS08KA1CDBR | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
MC9RS08KA1CDBR is in stock for immediate shipping now. We are the distributor of NXP Semiconductors all series components. The condition of MC9RS08KA1CDBR is new and unused, you can buy MC9RS08KA1CDBR NXP Semiconductors with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MC9RS08KA1CDBR.
