| Manufacturer Part Number: | MCP215XDM |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | MCP2150, MCP2155 - Interface, IrDA Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | MCP215XDM Datasheet |
| Internal Part Number | 898-MCP215XDM | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | PIC18 J Series MCU Overview | |
| Design Resources | Development Tool Selector | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Microchip Technology | |
| Series | - | |
| Part Status | Obsolete | |
| Main Purpose | Interface, IrDA | |
| Embedded | Yes, MCU, 8-Bit | |
| Utilized IC / Part | MCP2150, MCP2155 | |
| Primary Attributes | IrDA Controller with PIC18F MCU | |
| Secondary Attributes | Set up as a Data Logger with LCD, GUI, Socket for EEPROM, Battery Powerable | |
| Supplied Contents | Board, Power Supply | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | MCP215XDM | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
MCP215XDM is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of MCP215XDM is new and unused, you can buy MCP215XDM Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MCP215XDM.
