Manufacturer Part Number: | MDU93570 |
---|---|
Manufacturer: | Dialight |
Product Category: | LED Drivers |
Available Quantity: | 9102 Pieces |
Unit Price: | Quote by Email |
Description: | 700mA 4 ~ 32 V Constant Current LED Driver AC DC Converter Topology 1 Output |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MDU93570 Datasheet |
Internal Part Number | 898-MDU93570 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Lighting Product Selector | |
Online Catalog | MDU Series | |
Category | Power Supplies - External/Internal (Off-Board) | |
Family | LED Drivers | |
Manufacturer | Dialight | |
Series | MDU | |
Part Status | Active | |
Type | Constant Current | |
Topology | AC DC Converter | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 110VAC | |
Voltage - Input (Max) | 240VAC | |
Voltage - Output | 4 ~ 32 V | |
Current - Output (Max) | 700mA | |
Power (Watts) | 22W | |
Voltage - Isolation | - | |
Dimming | - | |
Features | OTP, OVP, SCP | |
Ratings | - | |
Operating Temperature | -20°C ~ 45°C | |
Efficiency | - | |
Termination Style | Wire Leads | |
Size / Dimension | 3.90" L x 1.53" W x 0.90" H (99.0mm x 39.0mm x 23.0mm) | |
Mounting Type | Chassis Mount | |
Approvals | CE, ENEC, UL | |
Weight | 0.001 KG | |
Standard Package | 20 | |
Application | Email for details | |
Replacement Part | MDU93570 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MDU93570 is in stock for immediate shipping now. We are the distributor of Dialight all series components. The condition of MDU93570 is new and unused, you can buy MDU93570 Dialight with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MDU93570.
