Manufacturer Part Number: | MIL2112B12NSD25 |
---|---|
Manufacturer: | C&K Components |
Product Category: | Rotary Switches |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Rotary Switch 12 Position SP12T 20mA (AC/DC) 50VAC Through Hole, Right Angle |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | MIL2112B12NSD25 Datasheet |
Internal Part Number | 898-MIL2112B12NSD25 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Switches | |
Family | Rotary Switches | |
Manufacturer | C&K Components | |
Series | MIL | |
Part Status | Obsolete | |
Number of Positions | 12 | |
Index Stops | Fixed | |
Number of Decks | 2 | |
Number of Poles per Deck | 1 | |
Circuit per Deck | SP12T | |
Contact Timing | Non-Shorting (BBM) | |
Current Rating | 20mA (AC/DC) | |
Voltage Rating - AC | 50V | |
Voltage Rating - DC | 50V | |
Actuator Type | Round (4mm Dia) | |
Actuator Length | 25.00mm | |
Angle of Throw | 30° | |
Contact Material | Brass | |
Contact Finish | Gold | |
Mounting Type | Through Hole, Right Angle | |
Termination Style | PC Pin | |
Features | Sealed - Fully | |
Depth Behind Panel | 35.56mm | |
Panel Cutout Dimensions | - | |
Operating Force, Torque | 6 N-cm | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | MIL2112B12NSD25 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
MIL2112B12NSD25 is in stock for immediate shipping now. We are the distributor of C&K Components all series components. The condition of MIL2112B12NSD25 is new and unused, you can buy MIL2112B12NSD25 C&K Components with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for MIL2112B12NSD25.
