| Manufacturer Part Number: | NCP380HMU05AATBG |
|---|---|
| Manufacturer: | ON Semiconductor |
| Product Category: | PMIC - Power Distribution Switches, Load Drivers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC CURRENT LIMIT SWITCH 6-UDFN |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | NCP380HMU05AATBG Datasheet |
| Internal Part Number | 898-NCP380HMU05AATBG | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | High-Side Power Distribution Switch Evaluation Board - NCP380HMUAJAGEVB Test Procedure High-Side Power Distribution Switch Evaluation Board - NCP380LMUAJAGEVB Test Procedure High-Side Power Distribution Switch Evaluation Board - NCP380LSNAJAGEVB | |
| PCN Obsolescence/ EOL | Multiple Devices 23/Jul/2013 | |
| PCN Packaging | Covering Tape/Material Chg 20/May/2016 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Manufacturer | ON Semiconductor | |
| Series | - | |
| Packaging | Digi-Reel® | |
| Part Status | Discontinued | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side | |
| Output Type | P-Channel | |
| Interface | On/Off | |
| Voltage - Load | 2.5 V ~ 5.5 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 2.1A | |
| Rds On (Typ) | 55 mOhm | |
| Input Type | Non-Inverting | |
| Features | Slew Rate Controlled, Status Flag | |
| Fault Protection | Current Limiting (Fixed), UVLO | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Package / Case | 6-UDFN Exposed Pad | |
| Supplier Device Package | 6-UDFN (2x2) | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | NCP380HMU05AATBG | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
NCP380HMU05AATBG is in stock for immediate shipping now. We are the distributor of ON Semiconductor all series components. The condition of NCP380HMU05AATBG is new and unused, you can buy NCP380HMU05AATBG ON Semiconductor with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for NCP380HMU05AATBG.
