| Manufacturer Part Number: | NGTB15N120IHRWG |
|---|---|
| Manufacturer: | ON Semiconductor |
| Product Category: | Transistors - IGBTs - Single |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IGBT Trench Field Stop 1200V 30A 333W Through Hole TO-247 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | NGTB15N120IHRWG Datasheet |
| Internal Part Number | 898-NGTB15N120IHRWG | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | On Semi - FL2 Series Field Stop 2 IGBTs | |
| PCN Assembly/Origin | Site Addition 09/Feb/2016 | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - IGBTs - Single | |
| Manufacturer | ON Semiconductor | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Active | |
| IGBT Type | Trench Field Stop | |
| Voltage - Collector Emitter Breakdown (Max) | 1200V | |
| Current - Collector (Ic) (Max) | 30A | |
| Current - Collector Pulsed (Icm) | 60A | |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 15A | |
| Power - Max | 333W | |
| Switching Energy | 340µJ (off) | |
| Input Type | Standard | |
| Gate Charge | 160nC | |
| Td (on/off) @ 25°C | -/170ns | |
| Test Condition | 600V, 15A, 10 Ohm, 15V | |
| Reverse Recovery Time (trr) | - | |
| Package / Case | TO-247-3 | |
| Mounting Type | Through Hole | |
| Supplier Device Package | TO-247 | |
| Standard Package | 30 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | NGTB15N120IHRWG | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
NGTB15N120IHRWG is in stock for immediate shipping now. We are the distributor of ON Semiconductor all series components. The condition of NGTB15N120IHRWG is new and unused, you can buy NGTB15N120IHRWG ON Semiconductor with us at a very low price and quick delivery.
