| Manufacturer Part Number: | PIM200FZ |
|---|---|
| Manufacturer: | GE Critical Power |
| Product Category: | DC DC Converters |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | MOD PWR ATCA INPUT 3.3V 200W T/H |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PIM200FZ Datasheet |
| Internal Part Number | 898-PIM200FZ | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Manufacturer Product Page | Power Module Wizard™ | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Manufacturer | GE Critical Power | |
| Series | PIM200X | |
| Packaging | Bulk | |
| Part Status | Obsolete | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 38V | |
| Voltage - Input (Max) | 75V | |
| Voltage - Output 1 | 3.3V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 2.4A | |
| Power (Watts) - Manufacture Series | 200W | |
| Voltage - Isolation | - | |
| Applications | ITE (Commercial) | |
| Features | OCP, OTP, UVLO | |
| Mounting Type | Through Hole | |
| Package / Case | Module | |
| Size / Dimension | 2.78" L x 1.45" W x 0.50" H (70.6mm x 36.8mm x 12.7mm) | |
| Operating Temperature | -5°C ~ 70°C | |
| Efficiency | 97% | |
| Power (Watts) - Max | 200W | |
| Standard Package | 20 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | PIM200FZ | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PIM200FZ is in stock for immediate shipping now. We are the distributor of GE Critical Power all series components. The condition of PIM200FZ is new and unused, you can buy PIM200FZ GE Critical Power with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PIM200FZ.
