| Manufacturer Part Number: | PM1812-151J-RC |
|---|---|
| Manufacturer: | Bourns Inc. |
| Product Category: | Fixed Inductors |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 150µH Unshielded Inductor 105mA 9 Ohm Max 1812 (4532 Metric) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | PM1812-151J-RC Datasheet |
| Internal Part Number | 898-PM1812-151J-RC | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Magnetic Product Overview | |
| RoHS Information | PM1812 Material Declaration | |
| 3D Model | PM1812.stp | |
| PCN Assembly/Origin | Magnetic products Oct/2013 | |
| PCN Packaging | CM453232,PM1812 Nov/2015 | |
| Online Catalog | PM1210 and PM1812 Series | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Manufacturer | Bourns Inc. | |
| Series | PM1812 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | - | |
| Material - Core | Ferrite | |
| Inductance | 150µH | |
| Tolerance | ±5% | |
| Current Rating | 105mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 9 Ohm Max | |
| Q @ Freq | 40 @ 796kHz | |
| Frequency - Self Resonant | 5MHz | |
| Ratings | - | |
| Operating Temperature | -40°C ~ 100°C | |
| Frequency - Test | 796kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 1812 (4532 Metric) | |
| Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) | |
| Height - Seated (Max) | 0.134" (3.40mm) | |
| Standard Package | 500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | PM1812-151J-RC | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
PM1812-151J-RC is in stock for immediate shipping now. We are the distributor of Bourns Inc. all series components. The condition of PM1812-151J-RC is new and unused, you can buy PM1812-151J-RC Bourns Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for PM1812-151J-RC.
