| Manufacturer Part Number: | RFANT3216120A5T |
|---|---|
| Manufacturer: | Walsin Technology Corporation |
| Product Category: | RF Antennas |
| Available Quantity: | 24478 Pieces |
| Unit Price: | Quote by Email |
| Description: | 2.4GHz Bluetooth, WLAN Chip RF Antenna 2.4GHz ~ 2.5GHz 2dBi Solder Surface Mount |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | RFANT3216120A5T Datasheet |
| Internal Part Number | 898-RFANT3216120A5T | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | IoT Product Selector | |
| Featured Product | Chip and External Dipole Antennas | |
| Online Catalog | Walsin Technology Corporation - Embedded | |
| Category | RF/IF and RFID | |
| Family | RF Antennas | |
| Manufacturer | Walsin Technology Corporation | |
| Series | - | |
| Packaging | Digi-Reel® | |
| Part Status | Active | |
| Frequency Group | UHF (2 GHz ~ 3 GHz) | |
| Frequency (Center/Band) | 2.4GHz | |
| Frequency Range | 2.4GHz ~ 2.5GHz | |
| Antenna Type | Chip | |
| Number of Bands | 1 | |
| VSWR | 2 | |
| Return Loss | - | |
| Gain | 2dBi | |
| Power - Max | - | |
| Features | - | |
| Termination | Solder | |
| Ingress Protection | - | |
| Mounting Type | Surface Mount | |
| Height (Max) | 0.047" (1.20mm) | |
| Applications | Bluetooth, WLAN | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | RFANT3216120A5T | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
RFANT3216120A5T is in stock for immediate shipping now. We are the distributor of Walsin Technology Corporation all series components. The condition of RFANT3216120A5T is new and unused, you can buy RFANT3216120A5T Walsin Technology Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for RFANT3216120A5T.
