Manufacturer Part Number: | RJH1CV7DPQ-E0#T2 |
---|---|
Manufacturer: | Renesas Electronics America |
Product Category: | Transistors - IGBTs - Single |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | IGBT Trench 1200V 70A 320W Through Hole TO-247 |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | RJH1CV7DPQ-E0#T2 Datasheet |
Internal Part Number | 898-RJH1CV7DPQ-E0#T2 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
EDA / CAD Models | Download from Accelerated Designs | |
Category | Discrete Semiconductor Products | |
Family | Transistors - IGBTs - Single | |
Manufacturer | Renesas Electronics America | |
Series | - | |
Packaging | Tube | |
Part Status | Active | |
IGBT Type | Trench | |
Voltage - Collector Emitter Breakdown (Max) | 1200V | |
Current - Collector (Ic) (Max) | 70A | |
Current - Collector Pulsed (Icm) | - | |
Vce(on) (Max) @ Vge, Ic | 2.3V @ 15V, 35A | |
Power - Max | 320W | |
Switching Energy | 3.2mJ (on), 2.5mJ (off) | |
Input Type | Standard | |
Gate Charge | 166nC | |
Td (on/off) @ 25°C | 53ns/185ns | |
Test Condition | 600V, 35A, 5 Ohm, 15V | |
Reverse Recovery Time (trr) | 200ns | |
Package / Case | TO-247-3 | |
Mounting Type | Through Hole | |
Supplier Device Package | TO-247 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | RJH1CV7DPQ-E0#T2 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
RJH1CV7DPQ-E0#T2 is in stock for immediate shipping now. We are the distributor of Renesas Electronics America all series components. The condition of RJH1CV7DPQ-E0#T2 is new and unused, you can buy RJH1CV7DPQ-E0#T2 Renesas Electronics America with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for RJH1CV7DPQ-E0#T2.
