| Manufacturer Part Number: | SRF1306-350Y |
|---|---|
| Manufacturer: | Bourns Inc. |
| Product Category: | Common Mode Chokes |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 35µH @ 100kHz 2 Line Common Mode Choke Chassis Mount 400 Ohm @ 5MHz 2.7A DCR 35 mOhm |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | SRF1306-350Y Datasheet |
| Internal Part Number | 898-SRF1306-350Y | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | SRF1306.stp | |
| PCN Assembly/Origin | Magnetic products Oct/2013 | |
| Online Catalog | SRF1306 Series | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Manufacturer | Bourns Inc. | |
| Series | SRF1306 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Filter Type | - | |
| Number of Lines | 2 | |
| Impedance @ Frequency | 400 Ohm @ 5MHz | |
| Inductance @ Frequency | 35µH @ 100kHz | |
| Current Rating (Max) | 2.7A | |
| DC Resistance (DCR) (Max) | 35 mOhm | |
| Voltage Rating - DC | 50V | |
| Voltage Rating - AC | - | |
| Operating Temperature | -40°C ~ 105°C | |
| Ratings | - | |
| Approvals | - | |
| Features | - | |
| Mounting Type | Chassis Mount | |
| Size / Dimension | 0.413" L x 0.374" W (10.50mm x 9.50mm) | |
| Height (Max) | 0.238" (6.05mm) | |
| Package / Case | 8-SMD, Gull Wing | |
| Standard Package | 600 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | SRF1306-350Y | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
SRF1306-350Y is in stock for immediate shipping now. We are the distributor of Bourns Inc. all series components. The condition of SRF1306-350Y is new and unused, you can buy SRF1306-350Y Bourns Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for SRF1306-350Y.
