Manufacturer Part Number: | TPS54020RUWT |
---|---|
Manufacturer: | Texas Instruments |
Product Category: | PMIC - Voltage Regulators - DC DC Switching Regulators |
Available Quantity: | 9510 Pieces |
Unit Price: | Quote by Email |
Description: | Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 10A 15-VFQFN Exposed Pad |
Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | TPS54020RUWT Datasheet |
Internal Part Number | 898-TPS54020RUWT | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | TPS54020 Design with WEBENCH® Power Designer | |
Manufacturer Product Page | TPS54020RUWT Specifications | |
EDA / CAD Models | Download from Accelerated Designs | |
Online Catalog | Buck (Step-Down) IC | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
Manufacturer | Texas Instruments | |
Series | SWIFT™, Eco-Mode™ | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Function | Step-Down | |
Output Configuration | Positive | |
Topology | Buck | |
Output Type | Adjustable | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 4.5V | |
Voltage - Input (Max) | 17V | |
Voltage - Output (Min/Fixed) | 0.6V | |
Voltage - Output (Max) | 5V | |
Current - Output | 10A | |
Frequency - Switching | 200kHz ~ 1.2MHz | |
Synchronous Rectifier | Yes | |
Operating Temperature | -40°C ~ 150°C (TA) | |
Mounting Type | Surface Mount | |
Package / Case | 15-VFQFN Exposed Pad | |
Supplier Device Package | 15-VQFN (3.5x3.5) | |
Standard Package | 250 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | TPS54020RUWT | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
TPS54020RUWT is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of TPS54020RUWT is new and unused, you can buy TPS54020RUWT Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for TPS54020RUWT.
