Manufacturer Part Number: | TSWA3NC LFS |
---|---|
Manufacturer: | C&K Components |
Product Category: | Navigation Switches, Joystick |
Available Quantity: | 9343 Pieces |
Unit Price: | Quote by Email |
Description: | Navigation Switch, 1 - Axis Digital (Mechanical Switch) Output |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | TSWA3NC LFS Datasheet |
Internal Part Number | 898-TSWA3NC LFS | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Introduction to Electromechanical Switches | |
RoHS Information | RoHS Cert of Compliance | |
Online Catalog | TSW Series | |
Category | Switches | |
Family | Navigation Switches, Joystick | |
Manufacturer | C&K Components | |
Series | TSW | |
Part Status | Active | |
Type | Navigation Switch, 1 - Axis | |
Actuator Type | Scroll Wheel | |
Switch Function | 360° Directional, Center Select | |
Functions, Extra | - | |
Output | Digital (Mechanical Switch) | |
Voltage - Supply | - | |
Current Rating | 1mA (DC) | |
Voltage Rating - AC | - | |
Voltage Rating - DC | 10V | |
Contact Material | - | |
Contact Finish | - | |
Mounting Type | Through Hole | |
Termination Style | PC Pin | |
Operating Temperature | 0°C ~ 40°C | |
Panel Cutout Dimensions | - | |
Ingress Protection | - | |
Features | - | |
Mechanical Life | 1,000,000 Cycles | |
Electrical Life | - | |
Operating Force | 220gf | |
Standard Package | 160 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | TSWA3NC LFS | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
TSWA3NC LFS is in stock for immediate shipping now. We are the distributor of C&K Components all series components. The condition of TSWA3NC LFS is new and unused, you can buy TSWA3NC LFS C&K Components with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for TSWA3NC LFS.
