| Manufacturer Part Number: | VNQ05XSP16 |
|---|---|
| Manufacturer: | STMicroelectronics |
| Product Category: | PMIC - Power Distribution Switches, Load Drivers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC SSR HIGH SIDE QUAD POWERSO16 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | VNQ05XSP16 Datasheet |
| Internal Part Number | 898-VNQ05XSP16 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Manufacturer | STMicroelectronics | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Obsolete | |
| Switch Type | General Purpose | |
| Number of Outputs | 4 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 5.5 V ~ 36 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 5A | |
| Rds On (Typ) | 110 mOhm (Max) | |
| Input Type | Non-Inverting | |
| Features | - | |
| Fault Protection | Current Limiting (Fixed), Over Temperature, Over Voltage | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | 16-PowerBSOP (0.370", 9.40mm Width) | |
| Supplier Device Package | PowerSO-16™ | |
| Standard Package | 50 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | VNQ05XSP16 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
VNQ05XSP16 is in stock for immediate shipping now. We are the distributor of STMicroelectronics all series components. The condition of VNQ05XSP16 is new and unused, you can buy VNQ05XSP16 STMicroelectronics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for VNQ05XSP16.
